Boost your productivity

The DX19 is built around the operator and provides optimal ergonomics.

The cab features large windows and narrow pillars to maximize all-around visibility, operator comfort and safety.

The hydraulic system makes the best possible use of the engine’s power. Fast cycle times, combined with smooth control of class-leading breakout forces, provide maximum productivity and versatility in operating a wide range of attachments.

For total peace of mind while working, the design features have been tested under extreme conditions, and the heavy steel gauge tailgate ensures extra durability.

Machine Specs
Operating weight (canopy / cab1.781 / 1.894 kg
Width (undercarriage retracted/expanded)980 / 1.360 mm
Max. reach ground level (Std. / long arm)4.039 / 4.214 mm
Max. digging depth (Std. / long arm)2.385 / 2.565 mm
Max. dumping height (Std. / long arm)2.566 / 2.693 mm
Max. digging force – Arm (Std. / long arm)10.4 / 9.3 kN
Max. digging force - Bucket20.8 kN
Engine (ISO 9249)9.9 kW / 13.3 HP
Max. reach ground level (short / long arm)4084 / 4257 mm
Max. digging depth (std / long arm)2395 / 2565 mm
Operating weight1.900 kg
Width1360 mm
EngineD722-EF11 (Stage V)
Options & Attachments

Quick Coupler

Part namePart #Pin Diameter mmMin - Max Centers x - y )mmBase Width  mmWeight  kg (lbs)
1-2t Quick CouplerQC25-30 (H)25 / 3085 - 2109518 (40)
