DX10Z
Boost your productivity
Compact is the word for the new Develon DX10Z!
At only 71 cm wide and with foldable TOPS, this mini excavator can sneak through most doors. And with zero tail swing, DX10Z allows you to work up against walls in the most confined spaces.
Yet this manoeuvrable mini excavator operates like many larger machines. The undercarriage can be extended to 1.10 m, providing the base for unbeatable lifting capacity. Inside, you have plenty of room for your legs, a quiet environment, and joystick positions you can adjust for your own comfort.
A compact mini excavator you’ll be delighted to work with!
Download Brochure
Find a DealerMachine Specs
| Operating weight | 1.176 kg |
| Engine power | 7.4 kW (9.9 hp) @ 2000 rpm |
| Width | 710 mm |
| Max. reach ground level | 3093 mm |
| Max. digging depth | 1820 mm |
| Max. dumping height | 1818 mm |
| Max. digging force - bucket | 8294 N |
| Max. digging force - arm | 5550 N |
| Travel speed fast / slow | 3.1 / 2.1 km/h |
| Max. reach ground level (standard/long arm) | 3145 / - mm |
| Max. digging depth (std / long arm) | 1820 / - mm |
| Engine | D722-EF15 (Stage V) |
