Boost your productivity

Designed to deliver superior performance and fuel efficiency, the Develon D18 diesel engine fully meets the latest Stage V emission regulations. To optimize machine performance, the engine uses high-pressure fuel injectors, air-to-air inter-cooler and electronic engine controls. 4-Cycle Water-Cooled, Wastegate Turbocharged, Diesel Oxidation Catalyst (DOC).

The air-conditioning and heating systems are integrated for optimal climate control. An automatically-controlled fan supplies the pressurized and filtered cab air, which is distributed throughout the cab from multiple vents. The heated air suspension, adjustable operator’s seat includes a seat belt. The operator can adjust the ergonomic seat and joystick console separately according to his preferences.

Machine Specs
Operating weight5438 kg
Bucket capacity0.16 m3
Emission standardStage V
EngineDevelon D18
Engine power36.4 kW / 48.8 hp at 2000 rpm
Maximum swing speed9.8 rpm
Maximum swing torque1380 kgf·m
Maximum traction4580 kg
Maximum gradeability35° / 70%
Width1980 mm
Max. reach ground level (standard/long arm)5800 mm
Max. digging depth (std / long arm)3480 mm
