Lift your business to the next level with the DX225LC-7 Develon excavator. Exceptionally powerful, yet environmentally friendly, the DX225LC-7 excavator features extraordinary fuel efficiency.

The new generation medium-sized Stage V compliant excavators - the new DX225LC-7 23 tonne crawler model. The DX225LC-7 is also the first Develon excavator of this size to feature Develon innovative D-ECOPOWER virtual bleed off (VBO) technology, providing operators with higher productivity and around 7% lower fuel consumption per hour than the previous Stage IV model, as well as smoother controls.

New Brand, Same Values
Machine Specs
Maximum power174 hp
Operating weight23.300 kg
Bucket capacity1.28 m3
Emission standardStage V
EngineDevelon DL06V
Number of cylinders6
Engine power129 kW / 174 hp @ 1800 rpm
Bucket capacity0.81 – 1.05 m³
Arm lenght2400 – 3500 mm
Boom lenght5700 – 5850 mm
BUCKET (Normal/Press. Up)15.6 - 16.5 t
ARM (Normal/Press. Up)9.7 - 13.4 t
Main pumps max flow2 × 210.6 l/min
Options & Attachments

Quick Coupler

Part namePart #Pin Diameter mmMin - Max Centers x - y )mmBase Width  mmWeight  kg (lbs)
16 - 29t Quick CouplerQC80 (H) (M)80385 - 530280/300628 (285)
16 - 29t Quick CouplerQC80 (H) (M)80385 - 530280/300628 (285)


Part namePart #Width mmCapacity m3Weight kg
Bucket H25-1500H25-150015001,091031
Bucket H25-1500H25-150015001,091031
