Designed to deliver superior performance and fuel efficiency, the Develon D34 diesel engine fully meets the latest Stage V emission regulations. To optimize machine performance, the engine uses high-pressure fuel injectors, air-to-air inter-cooler and electronic engine controls. 4-cycle water-cooled, wastegate turbocharged, Diesel Oxidation Catalyst (DOC), Selective Catalytic Reduction (SCR) and Diesel Particulate Filter (DPF).
The e-EPOS (Electronic Power Optimising System) is the brain of the excavator – minimising fuel consumption and optimizing the efficiency of the hydraulic system for all working conditions. To harmonize the operation of the engine and the hydraulics, the e-EPOS is connected to the engine’s electronic control unit (ECU) via a data transfer link.
|Maximum power||100 hp|
|Operating weight||10.7~11.100 kg|
|Bucket capaity||0.28 m3|
|Emission standard||Stage V|
|Engine power||75 kW / 100 hp at 2000 rpm|
|Maximum swing speed||10.5 rpm|
|Maximum swing torque||1820 kgf·m|
|Maximum traction force||4200 kg|
|Minimum turning radius||5738 mm (4 wheel steering: 3697 mm)|
|Gradeability||35° / 70%|
