DX250WMH-7

Operating weight

25397 kg (Gooseneck Arm)

Travel speed

4 - 9 - 20 km/h

Engine model

Develon DL06V

DX250WMH-7

Purpose-Built for Performance

The DX250WMH-7 is 25 tone Stage V compliant material handler for use in the solid waste, recycling, demolition and forestry industries.

More information

The DX250WMH-7 material handler has been designed specifically for a wide range of material sorting and handling applications such as those in the scrap metal and other solid waste and recycling industries, as well as logging. Designed to carry out the toughest tasks, the DX250WMH-7 is built with front and rear stabilizers, and a boom and arm specifically designed for material handling tasks. A standard feature is the hydraulic cab riser, which gives the operator better all-around visibility of the attachment and work area.

Specifications

Machine Specs

Operating weight25397 kg (Gooseneck Arm)
Travel speed4 - 9 - 20 km/h
Engine modelDevelon DL06V
Power (SAE J1995)189HP/141kW @1900rpm
Emission standardStageV
Max. Pin height12100 mm (Gooseneck Arm)



Max. Operation reach10700 mm (Gooseneck Arm)
Max. Working depth4700 mm (Gooseneck Arm)
Boom Length6500 mm (Gooseneck Arm)
Arm Length4500 mm (Gooseneck Arm)
Min. Swing radius2700 mm
Elevating height2500 mm

DX250WMH-7
