174 hp
23.3 t
1.28 m3
DX225LC-7X
The FEH is a VBO without pilot pressure lines. The joysticks and pedals are fully electric, but give the operator the same feeling as hydraulic joysticks. FEH sends an electric signal to the controller and as such is more precise and provides faster information. Back pressure and energy loss are therefore eliminated, by delivering the exact amount of oil needed. As we don’t have pilot pressure, we save energy, so we save fuel. In fact, FEH offers a very significant 8% less fuel burn compared to the VBO system. This is on top of the 7% decrease in fuel consumption already achieved in the standard DX225LC-7, compared to the previous DX225LC-5 model. The DX225LC-7X is equipped with the latest generation Develon engine. Stage V compliant, this engine boasts extremely low emissions because reducing our environmental impact is paramount to us.
At Develon, we are excited to offer you a significant upgrade for the DX225LC-7X excavator through our partnership with Leica Geosystems. Your DX225LC-7X already comes equipped with 2D machine guidance as a standard feature, allowing you to perform earthmoving tasks with precision and control.
Now, with the addition of the Leica MC1 3D machine guidance technology, you will be able to take on more complex projects that go beyond the capabilities of a 2D system. The MC1 retrofit kit integrates seamlessly with the existing Develon 2D system, giving you an easy-to-install, advanced 3D guidance solution.
This upgrade provides clear benefits for you. By moving from 2D to 3D, you gain greater flexibility and precision to handle more challenging construction tasks. With Leica technology, you can expect improved workflow optimization, seamless data sharing, and better project tracking. This collaboration ensures that your Develon excavator remains competitive and capable in modern heavy construction environments.
| Maximum power | 174 hp |
| Operating weight | 23.3 t |
| Buckets | 1.28 m3 |
| Emission standard | Stage V |
| Engine | Develon DL06V |
| Engine power | 129 kW/ 174 hp @1800 rpm |
| Bucket capacity | 0.81-1.05 m3 |
| Arm length | 2400-3500 mm |
| Boom length | 5700 mm |
| Main pumps max flow | 2 x 210.6 l/min |
DX225LC-7X
